Automotive Paint Booth Air Makleup Units

Home / Automotive Paint Booths / Air Makeup Automotive

Standard Equipment - All Units

- Vertical with Stand or Roof Mount
- Side,Top, or Bottom Discharge
- 100% Replacement Air
- 12,600 SCFM / 0.38 Duct SP
- ETL Label
- Deluxe Remote Control Panel
- Spray / Flash / Cure
- Variable Airflow Control System
- Automatic Booth Pressure Balancing
- 7.5 HP Motor - ODP
- High Efficiency EPACT Motor
- 7.5 H.P VFD for the Intake Fan
- 3 H.P VFD for Exhaust Fan
- V-Bank Pre Filter System with 2” Cleanable Filters
- Automatic Discharge Damper
- 120° F Temperature Rise
- 1.3 Million BTUH
- High Efficiency Motor
- 208-230-460/60/3 3-wire
- Burner Service Switch
- Aluminum Casting
- Outdoor Installation
- Gas Pressure: 7" to 5#
- Natural Gas or Propane
- Gas Manifold:ANSI
- 2 Solenoid Gas Valves
- 401M - Maxitrol Control System
- “M Series” Temperature Controller
- G-90 Galvanized Casing
- Flame Failure Light
- High Temp Limit
- Burner On/Off Intake Air Duct-Stat
- Fused Disconnect

Most Productive and Efficient System

Our standard heat and cure system features include a Variable Air Volume System (VAV) and Automatic Booth Pressure Balancing System (AB) which make our air makeup units stand out from the rest.

Variable airflow provides you with the most flexible and energy efficient system on the market. You set the desired airflow in the paint cycle flash cyle, and in the cure cycle.

With our VAV Variable Air Volume and AB Automatic Booth Pressure Balancing Systems you could cut operating costs by up to 50%. Save over $1,000 per year, more if you use the booth every day.

Nationwide Service through 100's of local service technicians located across the entire United States. These technicians are also avaliable for systen startup and training.

AB - Automatic Booth Pressure Balancing

The Automatic Balancing System speeds up or slows down the exhaust fan to keep the pressure balanced in the booth and the airflow at a proper speed. Set the pressure desired in the booth and the system will automatically adjust the speed of the exhaust fan to maintain the desired preset pressure.

VAV - Variable Air Volume Control System

Our pit downdraft paint booth variable air volume control systems give you precise control over the air flow when you are painting, flashing, and curing. This allows you to adjust for different types of paint ( solvent based, water based ), different sized pieces of work ( Go-Cart - Sprinter Van ), and different outside air conditions ( -10° F and 5% humidity - +95° F and 85% humidity ). The higher the humidity the greater the air flow required to efficiently flash or cure your paints.

Different tasks and different conditions require different airflow for optimum efficiency and quality. We offer the ability to flash and cure at 100% airflow and high temperatures. We can provide 100% airflow and a 120° F temperature rise over the outside air temperature. If it is 20° F outside our system can provide 100% airflow at 140° F. Most systems in the industry can only provide these temperature rises at 50% air flow.

We use special gas valving and controls coupled with a variable frequency drive for the air makeup unit motor to properly control airflow volume. Many just use a damper to “choke” off the airflow while the motor and gas are still running at 100%. Not efficient and not safe.

This system allows you to control how much air is used by the air make-up unit allowing you to control operational costs as well. System includes Variable Frequency Drives for both intake and exhaust volume control. Includes Programmable Digital Control Panel.

AEI Paint Booths - Automotive Booth Air Makeup Units

- Automotive Paint Booth 12,600 CFM Air Makeup Unit with Heat, Flash, and Cure, Variable Air Volume, Booth Pressure Auto Balance -

- Shop and Compare - More Standard Features - Most Cost Effective and Energy Efficient System - Works with Any Booth - $16,900 -

- Shop and Compare - More Standard Features - Most Cost Effective and Energy Efficient System - Works with Any Booth - $16,900 -
